Intel SC5650BCDP Technical Product Specification

Appendix B: Sensor Tables Intel
®
Server Board S5500BC TPS
Intel order number: E42249-009 Revision 1.8
130
Full Sensor Name
(Sensor name in SDR)
Sensor #
Platform
Applicability
Sensor Type
Event /
Reading Type
Event Offset
Triggers
Contrib. To
System Status
Assert
/ De-
assert
Readabl
e
Value /
Offsets
Event
Data
Rearm
Stand-
by
Fan Present Sensors
(Fan x Present)
40h–45h
Chassis-
specific
Fan
04h
Generic
08h
01 - Device
inserted
OK
As
and
De
-
Triggered
Offset
Auto
–
Fan Redundancy
1
(Fan Redundancy)
46h
Chassis-
specific
Fan
04h
Generic
0Bh
00 - Fully
redundant
OK
As
and
De
–
Trig Offset
A
01 - Redundancy
lost
Degraded
–
02 - Redundancy
degraded
Degraded
03 - Non-
redundant:
Sufficient
resources.
Transition from
redundant
Degraded
04 - Non-
redundant:
Sufficient
resources.
Transition from
insufficient.
Degraded
05 - Non-
redundant:
insufficient
resources.
Fatal
