Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 6 — Retrieving and Printing a Form
34 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
Once a form has been retrieved, it can be used over and over
again until another form is retrieved. All variable input data and
counter values are stored in the volatile memory, which means it
is lost when the printer loses power. If prompts are enabled,
existing data and counter values are displayed on the screen after
the related prompt. Any input data can be overwritten at will.
Command Explanation
? 
Call for variables in the same form

CR/LF to use existing data in V00

CR/LF to use existing data in V01
Sam 
Substitute data in variable V02
200000 
Substitute counter start value
P1,1 
Print 1 copy of 1 label

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
