Measuring Functions
Prerequisites for use of the measuring functions
115
Measuring Functions
The extended measuring functions of the VISIONREPORT inspection software are described below. You can call up these functions in the dia-
logue via the „Tools“ menu when creating an event. The extended measuring functions help you to log and also determine diagnoses concerning
damage points in the pipe quickly and directly.
Prerequisites for use of the measuring functions
Certain operating modes as provided as a precondition so that you can use the extended measuring functions:
- The operating mode must be in the general project.
- A catalogue must be selected in the current project.
- All necessary data is already entered in the current event.
- The crack width measurement is only possible if a camera with integral laser system is connected to the system.
- The pipe diameter in which you are presently operating must be entered in the current section.
NOTE!
If the preconditions for the measuring functions are not fulfi lled, either no measurements can be performed or the measured values
can have signifi cant deviations from the actual value. Make sure that your system is set exactly.
