Measuring Functions
Overview of the Measuring Functions
116
Overview of the Measuring Functions
You can perform the following measurements using the VISIONREPORT inspection software:
Measure cracks
You can measure cracks here using the camera’s integral laser.
Measure water level
You can measure the level of the water in the pipe here.
Measure bend
You can measure the radius, angle and rotation of a bend here.
Measure branch
You can measure the diameter, angle, rotation and distance of a branch here.
Measure pipe wall object
You can measure an object that is located on the curved pipe wall here. For example: deposit, depression, longitudinal crack.
Measure cross-section object
You can measure an object that is located on the cross section level / cylinder level of the pipe here. For example: tree root penetration, object
in the pipe.
