iPEK VISIONCONTROL VC200 - Using the Number Pad

Functional description
General screen dialogs
31
Number pad
Every numeric input on the VISIONCONTROL control panel must be entered via the integrated screen keypad. Whenever a numeric input is
required in an input field the screen keypad opens automatically when activating the field.
2
1
4 3
1 Input assistance:
2 Number pad
3 OK button to confirm the selection
4 Close dialog window without change / close the procedure
