Functional description
Range of applications
17
Functional description
Range of applications
The control panel VISIONCONTROL, in conjunction with the operating software VISIONREPORT, enables you to inspect pipeline systems,
and in parallel to collect inspection data in the form of videos and screenshots. Text and section markers can be overlaid in the running video
image to document and designate damage points. It is possible to save inspection and damage measuring data on the internal CF card. The data
is exchanged via the standardized interfaces USB and Ethernet. The VISIONREPORT operating software has been specially developed for the
VISIONCONTROL control panel and thus offers optimal possibilities for easy inspection.
The system is based on the Linux operating system and thus offers a high degree of security and the best possibilities for further development.
The VISIONCONTROL control panel is the perfect supplement to your ROVION
®
or AGILIOS™ sewer inspection system. Therefore it is
the universal control panel from iPEK for the AGILIOS™ as well as the ROVION
®
system. In case you have any SUPERVISION
®
crawlers
and cameras connected to your ROVION
®
system, you can control these, too. Furthermore you can use the VISIONCONTROL control panel
in conjunction with the REPORTABLEBOX in the office for editing data after the inspection and with the ROVVER
®
-System for doing the
documentation. The software always adapts itself to the connected devices.
Project types
The VISIONCONTROL control panel offers the best possibilities for data recording and processing, for simple, brief inspections, as well as for
long and detailed inspections. All project settings, as well as video, screenshot, and inspection data are stored within a project data structure. In
order to offer the user the greatest possible flexibility for his inspections, two different project types can be selected. Futhermore you can work
completely without any project using Direct Control. This is especially useful if you prefer to use another inspection software.
Simple project
If you are working within a simple project, you can directly start the inspection without any pre-configuration of the inspection. For a simple project
only videos can be recorded and screenshots can be taken, and freetexts can be overlaid. Events can only be created if a catalog is assigned to
the simple project. These events will not be stored, thus report generation is not possible.
General project
For a general project, in addition to screenshots and video recordings, detailed data displays and logs can be overlayed, as well as saved. The
selection of a catalog is mandatory in this case. It depends on your locale whether there is a catalog available or not
NOTE!
Prior to starting an inspection decide on the project type that you would like to work in. A detailed description of project types is
provided starting on Seite 56.
