Measuring Functions
Measured value description
125
Measured value description
The following table contains a complete overview of the individual measured values and a description of the measurements on which these values
are based.
Real Pipe
Diameter Diameter of the pipe to be inspected
Length Distance setting line 1 / setting line 2
Rotation Rotation of the setting lines around the pipe axis
Measure water level
Water Level Distance invert / water surface
Start Water level for setting line 1
End Water level for setting line 2
Rotation Rotation of the measuring lines around the pipe axis
Measure bend
Radius Radius of the neutral axis of the bend
Angle Angle between setting line 2 / measuring line 1
Rotation Rotation of the bend around the pipe axis
Measure branch
Diameter Diameter of the branched pipe
Angle Branch angle
Rotation Rotation of the branch around the pipe axis
Distance Distance setting line 1 / intersection of center axis branch and pipe wall of real pipe
