Measuring Functions
Measured value description
126
Measure pipe wall object
Grid Unit Grid spacing of the 3D wire grid
Distance Axial distance setting line 1 / measuring line 1
Rotation Rotation angle of the 3D wire grid around the center axis of the real pipe
Length Length of the 3D wire grid in the pipe axis direction
Arc Length Arc length of the 3D wire grid on the pipe wall
Measure cross-section object
Grid Unit Grid spacing of the 3D wire grid
Distance Axial distance setting line 1 / measuring line 1
Rotation Rotation angle of the 3D wire grid around the center axis of the real pipe
