Measuring Functions
Measure cracks
128
Measure cracks
If you have connected a camera with an integrated laser to your system, you can use it for crack measurement.
• You can change the brightness of the laser using the buttons 100%, 75%, 50% and OFF.
Two crosshairs are overlayed onto the camera picture. Move the centers of the crosshairs to the positions where the laser points are displayed.
• Select MARK LASER POINTS to calibrate the measurement system.
After that you can move the crosshairs around freely in the camera picture. On the top right of the screen the distance between both points is
shown. If necessary you can also change the position of the elevator in this dialog, you can also control the camera light or the camera zoom in
this dialog.
• Using the button COLOR and the expanding menu you can select the color of the crosshairs in order to get a better contrast between
foreground and background. If you choose to include the measurement into a photo, the same color will be used.
