Functional description
User interface
26
Inspection interface
40h 10min 13:50 Uhr0,00m / 743,33m
6
2
1
4
3
5
40h 10min 13:50 Uhr
1 Video image
2 Status bar with monitoring displays
3 Status bar with function displays
4 Touch screen buttons (referenced with R1 – R5 buttons on the VISIONCONTROL control panel)
5 Touch screen function menu buttons
6 Touch screen buttons (referenced with L1 – L5 buttons on the VISIONCONTROL control panel)
