3-16 Maxor Operator’s Manual www.javad.com
SETUP AND MEASURING
Measuring with the Maxor
3
Notice:
The reference geodetic coordinates you specify on this
tab relate to the antenna L1 phase center.
Figure 3-11. Base Tab Configuration
11. Select the Ports tab and set the following port parameters
(Figure 3-12 on page 3-17). Use serial port C for an internal PDL
and GSM modem.
• Output drop-down list – select type and format of differential
corrections.
• P
eriod (sec) – enter interv
al at which receiver will generate
differential corrections.
• Baud rate drop-d
own list – select a baud rate (i.e., the rate at which
differential messages will be transmitted from receiver to modem).
