SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
DISPLAY TEXT TYPE ID VALUE RANGE LOCATION DESCRIPTION
DUCT PRES RESET
BAS
Commun Port P1
User Disable /
User Enable
IPU Board
This Item Must Be Enabled In Order To
Communicate A Duct Static Pressure
Reset Value To The Unit
DUCT STATIC PRES
RESET BAS
Commun Port P1 0 To 100% IPU Board
The Duct Static Reset Value Being
Communicated To The Unit Through
The Bas System
EXHAUST CONTROL
BAS
Commun Port P1 Enable/Disable IPU Board
Enables or disables control of the
Modulating Exhaust Damper (Return
Fan)
EXHAUST DAMPER/
VFD
Commun Port P1 0 To 100% IPU Board
Communicates signal to set the position
of the Modulating Damper (Return Fan)
or speed of the Exhaust Fan.
FAN (G) BAS Commun Port P1 On / Off IPU Board
Gives The Status Of The
Communicated Fan G Input
MORNING WARM UP
CMD
Commun Port P1 On / Off IPU Board
Gives The Status Of The
Communicated Morning Warm Up
Command
OCCUPANCY
COMMAND
Commun Port P1
Occupied /
Unoccupied
IPU Board
Gives The Status Of The
Communicated Occupancy Command
SMOKE PURGE 1 BAS Commun Port P1 On Off IPU Board
Gives The Status Of The
Communicated Smoke Purge 1
Command
SMOKE PURGE 2 BAS Commun Port P1 On Off IPU Board
Gives The Status Of The
Communicated Smoke Purge 2
Command
SMOKE PURGE 3 BAS Commun Port P1 On Off IPU Board
Gives The Status Of The
Communicated Smoke Purge 3
Command
SAT RESET BAS Commun Port P1
User Disable /
User Enable
IPU Board
This Item Must Be Enabled In Order To
Communicate A Supply Air Temperature
Reset Value To The Unit
SUPPLY AIR TEMP
RESET BAS
Commun Port P1 0 To 5 Volts IPU Board
The Supply Air Temperature Reset
Value Being Communicated To The Unit
Through The Bas System
SYSTEM STOP Commun Port P1
0 - Allows All
Compressors
To Operate;
1 - Turns Off
Compressor
System 1;
2 - Turns Off
Compressor
System 2;
3 - Turns Off
Compressor
System 3
IPU Board
Gives The Status Of The
Communicated System Stop Command
UNDER FLR HUMI BAS Commun Port P1
User Disable /
User Enable
IPU Board
This Item Must Be Enabled In Order To
Communicate A Under Floor Humidity
Value To The Unit
UNDRFLOOR AIR
HUMIDITY BAS
Commun Port P1 0 To 100% IPU Board
The Under Floor Humidity Value Being
Communicated To The Unit
TABLE 51 – SERVICE (CONT'D)
