JOHNSON CONTROLS
139
SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
DISPLAY TEXT TYPE ID VALUE RANGE LOCATION DESCRIPTION
P1 STOP BITS 1-2
Do Not Change From Default Value For
BACnet
P2 BAUD RATE
1200, 4800,
9600, 19200,
38400, 57600
Establishes The Communication Baud
Rate For Port 2
P2 MANUAL MAC
ADDRESS
-1 To 127
Allows The Manual Entrance Of
The Mac Address For Port 2. See
Communication section on page 142.
P2 PARITY
None, Even,
Odd, Ignore
Establishes The Parity For
Communication Port 2
P2 PROTOCOL
Terminal,
Modbus I/O,
Modbus Server,
Api, Modbus
Client
Establishes The Protocol For
Communication Port 2
P2 STOP BITS 1 - 2
Establishes The Stop Bit Setting For
Communication Port 2
P3 BAUD RATE
1200, 4800,
9600, 19200,
38400, 57600
Establishes The Communication Baud
Rate For Port 3
P3 MANUAL MAC
ADDRESS
-1 To 127
Allows The Manual Entrance Of
The Mac Address For Port 3. See
Communication section on page 142.
P3 PARITY
None, Even,
Odd, Ignore
Establishes The Parity For
Communication Port 3
P3 PROTOCOL
Terminal,
Modbus I/O,
Modbus Server,
Api, Modbus
Client
Establishes The Protocol For
Communication Port 3
P3 STOP BITS 1 - 2
Establishes The Stop Bit Setting For
Communication Port 3
P4 BAUD RATE
1200, 4800,
9600, 19200,
38400, 57600
Establishes The Communication Baud
Rate For Port 4
P4 MANUAL MAC
ADDRESS
-1 To 127
Allows The Manual Entrance Of
The Mac Address For Port 4. See
Communication section on page 142.
P4 PARITY
None, Even,
Odd, Ignore
Establishes The Parity For
Communication Port 4
P4 PROTOCOL
Terminal,
Modbus I/O,
Modbus Server,
Api, Modbus
Client
Establishes The Protocol For
Communication Port 4
P4 STOP BITS 1 - 2
Establishes The Stop Bit Setting For
Communication Port 4
CONNEXSYS ERROR
FEATURE AND
DETECTION
Derived Not For Field Use
TABLE 51 – SERVICE (CONT'D)
