SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
BACNET
NAME
USER INTERFACE
NAME
READ/
WRITE
BACNET
OBJECT
TYPE AND
INSTANCE
MODBUS
REGISTER
ADDRESS
POINTS LIST DESCRIPTION
COMP_1A_
OPER
Comp 1A Operating
Hrs
R AI09 522 Displays The Operating Hrs Of Comp 1A
COMP_1B
Compressor 1B
Status
R BI04 1285
Displays The Status Of Comp 1B: 0=Off
1-On
COMP_1B_
OPER
Comp 1B Operating
Hrs
R AI10 523 Displays The Operating Hrs Of Comp 1B
COMP_2A
Compressor 2A
Status
R BI05 1286
Displays The Status Of Comp 2A: 0=Off
1=On
COMP_2A_
OPER
Comp 2A Operating
Hrs
R AI11 524 Displays The Operating Hrs Of Comp 2A
COMP_2B
Compressor 2B
Status
R BI06 1287
Displays The Status Of Comp 2B: 0=Off
1=On
COMP_2B_
OPER
Comp 2B Operating
Hrs
R AI12 525 Displays The Operating Hrs Of Comp 2B
COMP_3A
Compressor 3A
Status (70-150 Ton
Only)
R BI07 1288
Displays The Status Of Comp 3A: 0=Off
1=On
COMP_3A_
OPER
Comp 3A Operating
Hrs (70-150 Ton
Only)
R AI13 526 Displays The Operating Hrs Of Comp 3A
COMP_3B
Compressor 3B
Status (70-150 Ton
Only)
R BI08 1289
Displays The Status Of Comp 3B: 0=Off
1=On
COMP_3B_
OPER
Comp 3B Operating
Hrs (70-150 Ton
Only)
R AI14 527 Displays The Operating Hrs Of Comp 3B
COMP_
LPCO_1
Safety Input LPCO
Ckt 1 Status
R BI09 1290
Displays The Status Of The Low Press
Switch On Ckt 1: 0=Fault 1=No Fault
COMP_
LPCO_2
Safety Input LPCO
Ckt 2 Status
R BI10 1291
Displays The Status Of The Low Press
Switch On Ckt 2: 0=Fault 1=No Fault
COMP_
LPCO_3
Safety Input LPCO
Ckt 3 Status (70-
150 Ton Only)
R BI11 1292
Displays The Status Of The Low Press
Switch On Ckt 3: 0=Fault 1=No Fault
COMP_STAT_1
Safety Chain Ckt 1
Status
R BI12 1293
Displays The Status Of Ckt 1 Safety
Chain: 0=Fault 1=No Fault
COMP_STAT_2
Safety Chain Ckt 2
Status
R BI13 1294
Displays The Status Of Ckt 2 Safety
Chain: 0=Fault 1=No Fault
COMP_STAT_3
Safety Chain Ckt 3
Status (70-150 Ton
Only)
R BI14 1295
Displays The Status Of Ckt 3 Safety
Chain: 0=Fault 1=No Fault
COND_FAN_1A
Cond Fan 1A/1
Status
R BI15 1296
Displays The Status Of Cond Fan 1A/1:
0=Off 1=On
COND_FAN_1B
Cond Fan 1B/2
Status
R BI16 1297
Displays The Status Of Cond Fan 1B/2:
0=Off 1=On
COND_FAN_2A
Cond Fan 2A/3
Status
R BI17 1298
Displays The Status Of Cond Fan 2A/3:
0=Off 1=On
