JOHNSON CONTROLS
146
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 6 – USER INTERFACE CONTROL CENTER
TABLE 53 – BACNET MS/TP, MODBUS, BACNET IP (SEE NOTES AT END OF TABLE) (CONT'D)
BACNET
NAME
USER INTERFACE
NAME
READ/
WRITE
BACNET
OBJECT
TYPE AND
INSTANCE
MODBUS
REGISTER
ADDRESS
POINTS LIST DESCRIPTION
COND_FAN_2B
Cond Fan 2B/4
Status
R BI18 1299
Displays The Status Of Cond Fan 2B/4:
0=Off 1=On
COND_FAN_3A
Cond Fan 3A/5
Status (70-150 Ton
Only
R BI19 1300
Displays The Status Of Cond Fan 3A/5:
0=Off 1=On
COND_FAN_3B
Cond Fan 3B/6
Status (70-150 Ton
Only)
R BI20 1301
Displays The Status Of Cond Fan 3B/6:
0=Off 1=On
COND_FAN_
SPD
Cond Fan Speed R AI15 528 Not Used At This Time. For Future Use
CONTINU_
VENT
Continuous
Ventilation
(Constant Volume)
R/W AV79 BV03 1104
Displays The Status Of The Continuous
Ventilation Option And Allows For It To Be
Turned On/Off: 0=Off 1=On
DCT_ST_PR_
RT
Duct Static Press
Reset
R AI16 529
Displays The Status Of The Hardwired
Duct Static Reset Value To Ctb1 (%)
DCT_STAT_
PRS
Duct Static Press
Current (VAV Or
FlexSys)
R AI17 530
Displays The Actual Duct Static Press.
("W.C.)
DEW_PNT_
RST
Dew Point Reset
(FlexSys)
R/W AV80 BV04 1105
Allows The Dew Point Reset Feature To
Be Turned On/Off: 0=Off 1=On
DSP_HI_LIMIT
Duct Static Reset
High Sp (VAV Or
FlexSys)
R/W AV03 1028 Displays The Duct Static High Sp ("W.C.)
DSP_LO_LIMIT
Duct Static Reset
Low Sp (VAV Or
FlexSys)
R/W AV04 1029 Displays The Duct Static Low Sp ("W.C.)
DSP_RST_BAS
Duct Static Press
Reset BAS (VAV Or
FlexSys)
R/W AV05 1030
A BAS Value That Causes The Reset Of
The Duct Static Press Sp Between To High
And Low Values. "Duct Pres RST BAS"
Must Be Enabled Through The Service
Key To Use This Point (%)
ECON_ME_
USED
Econ Method Active R AI18 531
Displays The Status Of The Active
Economizer Mode: 1=Dry Bulb 2=Single
Enthalpy 3=Dual Enthalpy 4=Best Method
Avail
ECON_STATUS Econ System Status R AI19 532
Displays The Status Of The Economizer:
1=Installed And Active 2=Not Installed
3=Disabled
ECONO_
INSTAL
Economizer System R/W AV81 BV05 1106
Allows The Economizer Feature To Be
Turned On/Off: 0=Off 1=On
ECONO_
METHOD
Econ Method To
Use
R/W AV06 1031
Allows For The Selection Of The
Economizer Method To Use: 1=Dry Bulb
2=Single Enthalpy 3=Dual Enthalpy
4=Best Method Avail
EL_AIR_
TMP_H
Evap Leaving Air
Temp High Sp
(FlexSys)
R/W AV07 1032
Displays The Active Sp For The High
Evap Leaving Air Temp. This Is The Sp
The Compressors Are Controlled To (OCC
Cooling W/ Bypass)
