SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
BACNET
NAME
USER INTERFACE
NAME
READ/
WRITE
BACNET
OBJECT
TYPE AND
INSTANCE
MODBUS
REGISTER
ADDRESS
POINTS LIST DESCRIPTION
SMOKE_
PUR_1
Smoke Purge 1
Status
R BI56 1337
Displays The Status Of The Smoke
Purge 1 Input Either Hardwired Or
Communicated (On/Off)
SMOKE_
PUR_2
Smoke Purge 2
Status
R BI57 1338
Displays The Status Of The Smoke
Purge 2 Input Either Hardwired Or
Communicated (On/Off)
SMOKE_
PUR_3
Smoke Purge 3
Status
R BI58 1339
Displays The Status Of The Smoke
Purge 3 Input Either Hardwired Or
Communicated (On/Off)
SMOKE_
PUR1_B
Smoke Purge 1
BAS
R/W AV90 BV14 1115
A BAS Command That Allows Smoke
Purge 1 To Be Activated (0=Off 1=On)
SMOKE_
PUR2_B
Smoke Purge 2
BAS
R/W AV91 BV15 1116
A BAS Command That Allows Smoke
Purge 2 To Be Activated (0=Off 1=On)
SMOKE_
PUR3_B
Smoke Purge 3
BAS
R/W AV92 BV16 1117
A BAS Command That Allows Smoke
Purge 3 To Be Activated (0=Off 1=On)
STG_1_COOL
1st Stage Cooling
SP (CV/SZVAV)
R/W AV31 1056
Displays The Active Supply Air Temp Sp
For A 1St Stage Cooling Input (Y1)
STG_1_HEAT
1st Stage Heating
SP (CV/SZVAV)
R/W AV32 1057
Displays The Active Supply Air Temp Sp
For A 1St Stage Heating Input (W1)
STG_2_COOL
2nd Stage Cooling
SP (CV/SZVAV)
R/W AV33 1058
Displays The Active Supply Air Temp Sp
For A 2Nd Stage Cooling Input (Y2)
STG_2_HEAT
2nd Stage Heating
SP (CV/SZVAV)
R/W AV34 1059
Displays The Active Supply Air Temp Sp
For A 2Nd Stage Heating Input (W2)
SUP_AIR_
TEMP
Supply Air Temp
Current
R AI46 559 Displays The Actual Supply Air Temp. (°F)
SUP_AIR_
TRST
Supply Air Temp
Reset
R AI47 560
Displays The Value, 0-5 VDC, Of A
Hardwired Or Communicated Input That
Is Used To Reset The Supply Air Temp Sp
(VDC)
SUP_FAN_VFD
Supply Fan VFD
Speed
R AI48 561
Displays The Output From The Control To
The Supply Fan VFD (%)
SUPPLY_FAN
Supply Fan Output
Status
R BI59 1340
Displays The Status Of The Output From
The Controller To The Supply Fan Circuit
(0=Off 1=On)
SYSTEM_STOP System Stop R/W AV35 1060
Allows A BAS Command That Manually
Shuts Down Compressor Circuits (0=All
Ckts Can Operate 1=Shuts Down Ckt 1
2=Shuts Down Ckt 2 3=Shuts Down Ckt 3
SZ_MIN_VFD
Single Zone
Minimum VFD
R/W AV53 NA*
Allows the minimum supply fan speed to
be reset between 33% and 66% when
using SZVAV.
TEMP_1_SUCT Suct Temp Ckt 1 R AI49 562
Displays The Actual System 1 Suct Line
Temp (°F)
TEMP_1_
SUPER
Suct Superheat
Ckt 1
R AI50 563 Displays The System 1 Superheat (°F)
*Not Available
