JOHNSON CONTROLS
154
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 6 – USER INTERFACE CONTROL CENTER
BACNET
NAME
USER INTERFACE
NAME
READ/
WRITE
BACNET
OBJECT
TYPE AND
INSTANCE
MODBUS
REGISTER
ADDRESS
POINTS LIST DESCRIPTION
TEMP_2_SUCT Suct Temp Ckt 2 R AI51 564
Displays The Actual System 2 Suct Line
Temp (°F)
TEMP_2_
SUPER
Suct Superheat
Ckt 2
R AI52 565 Displays The System 2 Superheat (°F)
TEMP_3_SUCT
Suct Temp Ckt 3
(70-150 Ton Only)
R AI53 566
Displays The Actual System 3 Suct Line
Temp (°F)
TEMP_3_
SUPER
Suct Superheat Ckt
3 (70-150 Ton Only)
R AI54 567 Displays The System 3 Superheat (°F)
UND_FLR_
DEWP
Underoor Slab
Dew Point (FlexSys)
R AI55 568
Displays The Calculated Dew Point Of The
Underoor Air (°F)
UND_FLR_
HUMD
Underoor Air
Humidity (FlexSys)
R AI56 569
Displays The Humidity Value Of The
Underoor Air Thast The Unit Is Controlled
To (°F)
UND_FLR_
TEMP
Undeoor Slab
Temp (FlexSys)
R AI57 570
Displays The Temp Of The Underoor Air
That The Unit Is Contolling To (°F)
UND_HUMD_
BAS
Underoor Air
Humidity BAS
R/W AV36 1061
Allows The BAS System To Input An
Underoor Air Humidity Value To The
Control. (%) "Under Flr Humi BAS" Must
Be Enabled In The Service Menu For This
Point To Function
UND_TEMP_
BAS
Underoor Slab
Temp BAS
R/W AV37 1062
Allows The BAS System To Input An
Underoor Air Temp Value To The Control
(°F) "Under Flr Temp BAS" Must Be
Enabled In The Service Menu For This
Point To Function
UNIT_MODE Current Oper Mode R AI58 571
Displays The Current Operating Mode:
0=OCC Cool
1=OCC Cool Low
2=OCC Cool High
3=OCC Cool W/ Byp
4=OCC Cool W/O Byp
5= OCC Heat
6=OCC Heat Low
7=OCC Heat High
8=OCC Standby
9=UNOCC Cool
10=UNOCC Cool Low
11=UNOCC Cool High
12=UNOCC Heat
13=UNOCC Heat Low
14=UNOCC Heat High
15=UNOCC Standby
16=Comfort Vent Cool
17=Comfort Vent Heat
18=Night Set-Back
19=Morning Warm-Up
20=Power Up Standby
TABLE 53 – BACNET MS/TP, MODBUS, BACNET IP (SEE NOTES AT END OF TABLE) (CONT'D)
