JOHNSON CONTROLS
155
SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
BACNET
NAME
USER INTERFACE
NAME
READ/
WRITE
BACNET
OBJECT
TYPE AND
INSTANCE
MODBUS
REGISTER
ADDRESS
POINTS LIST DESCRIPTION
UNIT_STOP Unit Stop R/W AV93 V17 1118
A BAS Command That Allows The Unit
To Be Shut Down (0=Normal Operation
1=Unit Stopped)
UNSTABLE_
SYS
Unstable System
Status (Not Used)
R BI60
UNOCC_ZN_
COOL
UNOCC Zone
Cooling Sp
R/W AV38 1063 UNOCC Zone Cooling Sp
UNOCC_ZN_
HEAT
UNOCC Zone
Heating Sp
R/W AV39 1064 UNOCC Zone Heating Sp
VAV_HEAT
VAV Heat Relay
Status
R BI61 1342
Displays The Status Of The Output That
Energizes A VAV Heat Relay (Off/On)
VENT_
CONTROL
Ventilation Control R/W AV94 BV18 1119
A BAS Command That Allows The
Selection Of The Ventilation Function
(0=Fixed Minimum 1=Demand)
VENT_DEM_
OUT
Ventilation Demand R AI59 572
Displays The Status Of The Ventilation
Output For Demand Ventilation (%)
VENT_ENABLE Ventilation System R/W AV95 BV19 1120
A BAS Command That Allows The
Ventilation Function To Be Turned On Or
Off (0=Off 1=On)
W1_LO_
HEAT_B
W1 Lo Heat BAS
(CV Only)
R/W AV96 BV20 1121
A BAS Command That Allows An Input For
W1, First Stage Heat (0=Off 1=On)
W1_LOW_
HEAT
W1 Low Heat
Status
R BI62 1343
Displays The Status Of The W1 Heat Input
Either Hardwired Or Communicated From
A BAS (On/Off)
W2_HI_
HEAT_B
W2 High Heat BAS
(CV Only)
R/W AV97 BV21 1122
A BAS Command That Allows An Input For
W2, Second Stage Heat (0=Off 1=On)
W2_HIGH_
HEAT
W2 High Heat
Status
R BI63 1344
Displays The Status Of The W2 Heat Input
Either Hardwired Or Communicated From
A BAS (On/Off)
Y1_LO_
COOL_B
Y1 Lo Cool BAS
(CV Only)
R/W AV98 BV22 1123
A BAS Command That Allows An Input For
Y1, First Stage Cool (0=Off 1=On)
Y1_LOW_
COOL
Y1 Low Cool Status R BI64 1345
Displays The Status Of The Y1 Cool Input
Either Hardwired Or Communicated From
A BAS (On/Off)
Y2_HI_
COOL_B
Y2 High Cool BAS
(CV Only)
R/W AV99 BV23 1124
A BAS Command That Allows An Input For
Y2, Second Stage Cool (0=Off 1=On)
Y2_HIGH_
COOL
Y2 High Cool Status R BI65 1346
Displays The Status Of The Y2 Cool Input
Either Hardwired Or Communicated From
A BAS (On/Off)
ZONE_TEMP Zone Temp Current R AI60 573 Displays The Actual Zone Temperature (°F)
ZONE_TEMP_
BAS
Zone Temp BAS R/W AV40 1065
Allows The BAS System To Input An Zone
Temperature Reading (°F) The Control
Method Must Be Set To "Comm Zone
Temp" For This Point To Function
NOTES
1. The most up to date listing of the Standard Points Mapping can be found on the Johnson Controls website
2. For a Building Automation System using BACnet IP, a gateway must be used, since the IPU board does not have a BACnet IP port. We
recommend using a Johnson Controls NCE (MS-NCE2560-0)
TABLE 53 – BACNET MS/TP, MODBUS, BACNET IP (SEE NOTES AT END OF TABLE) (CONT'D)
