JOHNSON CONTROLS
25
SECTION 2 – INSTALLATION
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
2
75 - 105 TON MODELS
MODEL SIZE 075 080 090 105
Filters -12” Rigid 65%, 2” 30% Prefilter (Pre-Filter Position)
Quantity 2 / 8 / 9 2 / 8 / 9 8 / 12 8 / 12
Size (length x width) (in.) 16x20/25x16/25x20 16x20/25x16/25x20 25x16/25x20 25x16/25x20
Total Filter Face Area (square feet) 55.8 55.8 61.6 61.6
Filters -12” Rigid 95%, 2” 30% Prefilter (Pre-Filter Position)
Quantity 2 / 8 / 9 2 / 8 / 9 8 / 12 8 / 12
Size (length x width) (in.) 16x20/25x16/25x20 16x20/25x16/25x20 25x16/25x20 25x16/25x20
Total Filter Face Area (square feet) 55.8 55.8 61.6 61.6
Filters - 2” Carbon (Pre-Filter Position)
Quantity 10 / 15 10 / 15 12 / 18 12 / 18
Size (length x width) (in.) 25x16 / 25x20 25x16 / 25x20 25x16 / 25x20 25x16 / 25x20
Total Filter Face Area (square feet) 77.1 77.1 92.5 92.5
Filters - 12” Rigid 95% In Post-Filter Position
Quantity 10 / 15 10 / 15 12 / 18 12 / 18
Size (length x width) (in.) 25x16 / 25x20 25x16 / 25x20 25x16 / 25x20 25x16 / 25x20
Total Filter Face Area (square feet) 77.1 77.1 92.5 92.5
Gas Furnace
Staged Furnace Sizes
(input/output/stages)
375 mbh / 300 mbh / 2 stages
750 mbh / 600 mbh / 4 stages
1125 mbh / 900 mbh / 6 stages
Inlet Gas Pressure
Range (min. to max. iwg)
Natural 4.5–10.5 iwg
Propane 11.0–13.0 iwg
Minimum Air ON Temperature 6,950–36,000 11,150–36,000 15,150–36,000 15,150–36,000
Airow Range (min. to max. cfm) 375 mbh / 300 mbh / 8:1 turndown
Modulating Furnace Sizes
(input/output/turndown)
750 mbh / 600 mbh / 16:1 turndown
1125 mbh / 900 mbh / 24:1 turndown
4.5–10.5 iwg
Inlet Gas Pressure
Range (min. to max. iwg)
Natural 11.0–13.0 iwg
Propane 8,250–36,000 11,150–36,000 15,150–36,000 15,150–36,000
Minimum Heat Exchanger Entering Supply
Air Temperature
40 °F
Electric Heaters
Size Range (min. to max. kW) 80–200 108–250 108–250 108–250
Heating steps
1
2–6 2–6 2–6 2-6
Minimum Outside Air Temp. for Mech.
Cig.
45 45 45 45
Low Ambient Option Min. Outside Air
Temp
0 0 0 0
1. Electric heat steps and airow range depends on voltage and size. Consult the air pressure drop tables for specic number of steps for a
given voltage.
2. Weights are for components only and need to be added to the extended cabinet weights. The diffuser is required in the extended cabinet
for any unit with hot water or nal lter option.
TABLE 3 - PHYSICAL DATA (CONT'D)
