3.6 DISPLAY OWN SHIP’S TRACK
y
y y
Own Track Setting
1. Own Track Interval
1 min
2. DISP Own Track Color>
3. Clear Own Track
ALL
4. Own Track Memory
ON
5. Track Color
CYAN
6. Track Memory
NORMAL
7. Num/Vector Display
OFF
9. NEXT >
0. EXIT
1. OFF
2. WHITE
3.
CYAN
4.
BLUE
5. GREEN
6. YELLOW
. PINK
8. RED
3.6 DISPLAY OWN SHIP’S TRACK
3.6.1 Display Own Ship’s Track (Display Own Track)
If navigation equipment is connected, this system records data received from the navigation equipment and
displays the own ship’s track.
1 Select color for new own ship past tracks. (Own Track Color)
Procedures 1 Press [RADAR MENU] key twice.
Press [9] key.
Press [1] key.
The Own Track Setting Menu will appear.
2 Press [5] key.
The color list is displayed.
3 Select the number to be set,
pressing the numeric key.
The selected track colorl will be set.
* Button
28
on the radar display on page 2-7 is also available to
select the Own Track color.
The selected color is applied to the newly displayed track only.
The tracks displayed already are not affected by the setting.
Note: The own ship’s track can be displayed even while Own Track Memory is set to OFF. In this
case, if rewrite operation such as changing of the display range is performed for the radar
display, the own ship’s track display is erased and the track is not plotted again.
If DISP Own Track is set to OFF when Own Track Memory is ON, the own ship’s track is not
shown on the radar display but the system stores own ship’s track data at specified intervals.
