11.9 PLOTTER UNIT
11.9 PLOTTER UNIT
(1) Plotter (Normal) (Synthesis mode)
Projection: Mercator projection (Latitude 70 degree or less.)
Scale: Radar synchronize range scale
Own ship trail: Color of 1 stage.
Interval of storage 3/5/10/30 sec, 1/3/5/10/30/60 min or
every 0.1/0.2/0.3/0.5/1/3/5/10 nm and OFF
Cursor mark : Storage Capacity 7,000 point
Coastline data : Coastline ROM Card(Option) (ERC, JRC, C-Map NT+)
One selected isobath can be displayed.
Painting out: ON/OFF can be selected.
(2) Plotter (Option) (Synthesis mode)
Projection: Mercator projection (Latitude 70 degree or less.)
Scale: Synchronize range scale
Own ship trail: Color of 7 stages.
Interval of storage: 3/5/10/30 sec, 1/3/5/10/30/60 min or
every 0.1/0.2/0.3/0.5/1/3/5/10 nm and OFF
Storage capacity of own ship trail: 7,000 point
Cursor mark: Color of 7 stages
Storage capacity of cursor mark: 20,000 point
Variety of cursor Mark: 19
Event mark: Color of 7 stages
Storage capacity of event mark: Include in cursor mark
Variety of event mark: 3 kinds, (Two kinds can be switched.
/8 form to selection.)
Variety of external event mark: One kind, Monochrome
Line: Color of 7 stage
Storage capacity of line: Include in cursor mark
Variety of line: Solid line, broken line, alternate long and
short dash line
Coast line data: Coast line ROM card (Option)(ERC, JRC, C-Map NT+)
Selected one isoline can be displayed.
Painting out: ON/OFF can be selected.
External memory: Memory card (Option)
Destination and sea route: Destination can be set up to 99 point.
Information of destination: Azimuth, distance and the time
to required destination.
Setting of sea route: 10 sea routes. (10 destination for one
sea route can be set.)
Alarm of sea route: Destination, Secession, Invetion,
Secession
Position compensation: Radar display synchronize range scale coast line by manual.
