8─37
Equipment Setup
1. Bearing Adjustment
0.0°
2. Range Adjustment
0
0
8. INSTALLATION >
0. EXIT
3. Tune Adjustment
4. TRX Setting >
5. COM Port Setting >
6. NAV Setting >
7. Sector Blank >
9. Language
ENGLISH
Bearing Adjustment
Adjust the bearing so that bearing of the target measured with the ship’s compass matches that of the target
echo on the radar display.
Procedures 1 Press AZI MODE to select the relative
bearing presentation [H UP] mode. Set
Image Processing to OFF.
[AZI MODE] → Button
5
on the Radar Menu
Image Processing → Button
12
in the Radar
Menu
2 Measure the bearing of an adequate
target (for example, a ship at anchor, a
breakwater or a buoy) relative to own
ship’s heading.
3 Open the Equipment Setup Menu.
4 Press [1] key.
The Code Input Menu will appear.
5 Using numeric key, enter the value
and then press “ENT” button, and
press “EXIT” button to determine the
value.
The multi-function control can also be used to
enter the value.
6 Repeat Step 5 above, and adjust to
display the target measured in Step 2
to the measured bearing.
Exit 1 Press [RADAR MENU] key.
The Main Menu will reappear.
To Next Page
