3─12
3
3.3 PREPARATION
y
y y
Display Color Setting
1. Day/Night
DAY1
2. Colour Scheme
ORIGINAL
3. Outer PPI
GRAY
4. Inner PPI
BLACK
5. Character
WHITE
6. RADAR Echo
YELLOW
7. RADAR Trails ( Time )
CYAN
8. RADAR Trails ( Cont )
WHITE
9. HL/Vector/ATA/AIS
WHITE
0. EXIT
DAY11.
DAY22.
NIGHT13.
NIGHT24.
3.3.8 Set Display Color
For each day/night mode, set the colors of the background outside the bearing scale, the background inside the
bearing scale, characters, radar echoes, and radar trails.
Color Adjustment by Menu Operation
Day/Night Registers the switching of a day/night mode.
Color Scheme Calls a preset color scheme pattern.
Outer PPI Adjusts the background color outside the bearing scale.
Inner PPI Adjusts the background color inside the bearing scale.
Character Adjusts the colors of characters and bearing scales.
RADAR Echo Adjusts the colors of radar echoes.
RADAR Trails Adjusts the colors of radar trails.
Time: Display interval time is selected.
Cont:
Continuous display
HL/Vector/ATA/AIS Adjusts the colors of HL, Vectors, ATA symbols, AIS symbols.
Selecting a Day/Night Mode (Day/Night)
Select the mode for which color setting is to be changed.
Procedures 1 Press [RADAR MENU] key twice.
Press [4] key.
Press [1] key.
The Display Color Setting Menu will
appear.
2 Press [1] key.
The Day/Night mode selection screen will
appear.
3 Select the mode number for color
adjustment, pressing the numeric
keys [1] to [4].
The mode will be selected.
