4.4 MEASUREMENT BETWEEN TWO
OPTIONAL POINTS
Procedures 1 Press [EBL2] key to select EBL2 display and operation.
The EBL2 indication at the lower right of the radar display will be selected and the
EBL2 will appear as a dotted-line on the PPI display.
T EBL1 123.4 C
°
T EBL2 004.3 C
°
2 Point the cursor to the C
switch of EBL2 at the lower
right of the radar display, and
press [ENT] key. The EBL cursor mode changes
each time O or L is pressed.
3 Using the trackball, move the starting point of EBL2 to one
(A) of the two points and press [ENT] key.
(See Figure 4.3.)
4 Turn the [EBL] control to move EBL2 to the other point (B).
(See Figure 4.3.)
5 Press [VRM2] key to select VRM2 display and operation.
{ (VRM marker) will appear on a dotted-line of the EBL2.
6 Using the [VRM] control, move the VRM2 marker on a
dotted-line of EBL2 to the point B.
The bearing and range between the two points will appear in the VRM2 and EBL2 area
on the lower right of the radar display.
4─5
