8─2
8
8.1 Performance Check
yyyy
yyyy
est Menu
1. Self Test
2. Monitor Test
3. Keyboard Test
4. PM Display
ON
5. Error Logging
6. System INFO
0. EXIT
MAGI
Check Performance on Test Menu
The performance status of this radar equipment can be checked on the TEST Menu.
Self Test
[I] Self-diagnostic function
Monitor Test
[II] Monitor check
Keyboard Test
[III] Operation panel check
PM Display
[IV] Performance monitor
Error Logging
[V] Error log display
System INFO
[VI] System information display
MAGI
[VII] Indication of magnetron current
* Execution of PM Display requires a PM unit.
Procedures 1 Press [RADAR MENU] key twice.
Press [8] key.
Press [9] key.
The TEST Menu will appear.
* Button
57
on the radar display on page 2-7 is also available.
2 Select the check item you want to
check, pressing the numeric keys [1]
to [6] on Test Menu.
The list of check items will appear.
Exit 1 Press [RADAR MENU] key.
The TEST Menu will be closed.
To Next Page
