3─97
3.10 APPLIED OPERATIONS
3.10.1 Set Radar Signal Processing (Process Setting)
This function enables the setting of detail information about radar signal processing.
Procedures 1 Press [RADAR MENU] key twice.
Press [1] key.
The Process Setting Menu will appear.
Detail information about radar signal
processing can be set by changing the settings
of the menu items.
Note: After the settings for radar signal processing are
changed, small targets may not be displayed or
unwanted waves may not be suppressed. Thus, do
not make a significant change in the settings.
[1] Video Latitude
• Select the dynamic range in which receiving signals are to be shown on the radar display.
• Select NORMAL in standard, and WIDE in rainy weather.
• NARROW clearly displays short-range videos when STC is used in manual mode.
NORMAL : Standard setting
The dynamic range varies depending on the actual range:
Short range > long range
WIDE : Use this mode when rainy weather intensifies unwanted waves.
The dynamic range is about twice as wide as when NORMAL is selected.
SUPER WIDE : Use this mode when rain cloud remain at WIDE mode.
The dynamic range is about twice as wide as when NORMAL is selected.
NARROW : Narrows the dynamic range at short range.
Process Setting
1. Video Latitude
NORMAL
2. Video Noise Rejection
LEVEL1
3. Auto DR Control
ON
4. Process Switch
OFF
5. 2nd Process Mode
REMAIN
6. Process Switch Range
6.2nm
7. Fast Target Detection
OFF
8. User Function Setting
0. EXIT
To Next Page
