3─10
3
3.3 PREPARATION
y
y y
Brilliance Setting
1. RADAR Video
LEVEL4
2. RADAR Trails
LEVEL4
3. ATA/AIS
LEVEL3
4. Fix Marker
LEVEL2
5. EBL/VRM
LEVEL2
6. Character
LEVEL4
7. Panel
LEVEL4
0. EXIT
LEVEL1
1.
LEVEL2
2.
LEVEL3
3.
LEVEL4
4.
3.3.5 Adjust Brilliance of Information on Radar Display
(Brilliance Setting)
Brilliance can be adjusted for each item of information on the radar display by operating the menu.
RADAR Video Adjusts the brilliance of radar echoes.
RADAR Trails Adjusts the brilliance of radar trails.
ATA/AIS Adjusts the brilliance of ATA symbols and AIS symbols.
FIX Marker Adjusts the brilliance of fixed range markers.
EBL/VRM Adjusts the brilliance of variable range markers (VRM1 and VRM2) and
electronic bearing lines (EBL1 and EBL2).
Character Adjusts the brilliance of characters.
Panel Adjusts the brilliance of operation panel.
Procedures 1 Press [RADAR MENU] key twice.
Press [4] key.
Press [2] key.
The Brilliance Setting Menu will appear.
2 Select the item for which brilliance is
to be adjusted, pressing the numeric
keys [1] to [7].
The pull-down menu will appear showing the
brilliance levels.
3 Select the brilliance level number to be
set, pressing the numeric key.
The selected brilliance level will be set.
To change the setting of another item, repeat
steps 2 and 3.
Exit 1 Press [RADAR MENU] key.
The menu will be closed.
Note: The brilliance levels set here are saved in accordance with the day/night mode.
