3─125
3.11.2 Function Setting Menu Items
The function setting menu has the items below.
Page 1
Page 2
Page 3
Page 4
Page 5
1. Mode Name of the mode to be used
2. IR Radar interference rejection OFF/LOW/MEDIUM/HIGH
3. Process Video process OFF/････
4. Target Enhance Target expansion OFF/ LEVEL1/LEVEL2/LEVEL3
5. Auto STC/FTC Automatic clutter suppression OFF/AUTO SEA/AUTO RAIN
7. Save Present State Saving of the present state
1. PL 0.75nm Standard pulse length of 0.75 nm range SP/MP
2. PL 1.5nm Standard pulse length of 1.5 nm range SP/MP/LP
3. PL 3/4nm Standard pulse length of 3 nm range SP/MP/LP
4. PL 6/8nm Standard pulse length of 6 nm range SP/MP/LP
5. PL 12nm Standard pulse length of 12 nm range SP/MP/LP
6. PL 16nm Standard pulse length of 16 nm range SP/MP/LP
1. Video Latitude Dynamic range of radar video NORMAL/WIDE/NARROW
/SUPER WIDE
2. Video Noise Rejection Radar video noise rejection OFF/LEVEL1/LEVEL2
3. Auto DR Control Automatic dynamic range control OFF/ON
4. Process Switch Radar video process switching OFF/RANGE FIX/AUTO
5. 2nd Process Mode Second video process mode OFF/････
6. Process Switch Range Video process switching range Range setting
7. Fast Target Detection Fast moving target detection OFF/ON
1. Trails Interval Radar trails length OFF/････
2. Trails Mode Radar trails mode TRUE/RELATIVE
3. Trails REF Level Radar trails plotting threshold LEVEL1-4
4. Trails Reduction Thinning of radar trails OFF/LEVEL1-3
5. Time/Cont Combine Superimpose-display of time radar
trails and continuous radar trails OFF/ON
6. Trails Process Radar trails video process OFF/ON
7. Max Interval Maximum time for radar trails display
SHORT/MEDIUM/LONG/SUPER LONG
1. Gain Offset Sensitivity correction Correction value setting
2. XMIT Repetition FREQ Transmitting repetition frequency NORMAL/ECONOMY/HIPOWER
3. Small Buoy Detection Small target detection mode OFF/ON
4. Fishnet Detection Fishnet detection mode OFF/ON
5. Antenna Height Antenna height DEFAULT/-5m/5-10m/10-20m/20m
To Next Page
