11.12 INPUT ENABLE SIGNAL
11.12 INPUT ENABLE SIGNAL
(1) Navigation equipment: NMEA0183
Receive capability sentence.
Longitude/Latitude: GGA>RMC>RMA>GNS/GLL
Waypoint: RMB>BWC(BWR)
COG/SOG: RMC>RMA>VTG
SPEED: VBW
Day/Time information: ZDA
Rate of Turn : ROT
Rudder : RSA
(2) Bearing signal: GYRO-SYNC: 360X, 180X, 90X, 30X. (Require optional NSK
unit)
GYRO-STEP: 360X, 180X, 90X, 30X. (Require optional NSK
unit)
JRC-NSK format (JLR-10)
IEC61162-2 38400bps: HDT
IEC61162-1: HDT>HDG>HDM>VHW
※Can’t be use for ATA.
(3) Speed signal: LOG-SYNC: 360X, 180X,90X, 30X. (Require optional NSK
unit)
LOG-PULSE: 800, 400, 200, 100. (Require optional NSK unit)
(4) External event mark: Contact input by way of terminal board.
(5) Radar buoy: Negative input
(6) Depth: DPT>DBK>DBT>DBS
(7) Water temperature: MTW
(8) Tendency: CUR, JRC format
(9) Direction of wind, velocity of wind: MWV, MWD
