3.10 APPLIED OPERATIONS
y
y y
RADAR Trails Setting
1. Trails Interval
6 min
2. Trails Mode
RUE
3. Trails REF Level
LEVEL2
4. Trails Reduction
OFF
5. Time/Cont Combine
OFF
6. Trails Process
OFF
7. Max Interval
SHORT
9. NEXT >
0. EXIT
3.10.2 Set Radar Trails (RADAR Trails Setting)
This function enables the setting of detail information about radar trails processing.
Procedures 1 Press [RADAR MENU] key twice.
Press [2] key.
The RADAR Tails Setting Menu will appear.
Detail information about radar trails
processing can be set by changing the settings
of the menu items.
Note: After the settings for radar trails processing are changed,
targets’ trails may not be displayed or trails may be plotted
with unwanted waves. Thus, do not make a significant
change in the settings.
[1] Trails Interval
• Set the trail intervals at which radar trails are displayed.
• Selection items of trail intervals change depending on the
setting of maximum value of radar trail display time.
• The Multi-function control is also available for setting.
• For the decision branches of trail interval, see Section 3.5.9
on page 3-45.
[2] Trails Mode
• Set the radar trail display mode.
• Each time the button is pressed, you can switch between True and Relative.
• For details on the trail mode, see Section 3.5.9 on page 3-43.
[3] Trails REF Level
• Select a radar video level required for plotting radar trails.
• The radar video level increases in order of LEVEL1 → LEVEL2 → LEVEL3 →
LEVEL4 .
• To plot radar trails with unwanted waves, change to a higher level.
• To thin radar trails, change to a higher level.
• If radar trails are plotted in snatches, change to a lower level.
[4] Trails Reduction
• Make a setting for thinning radar trails.
• The effect of thinning increases in order of LEVEL1 → LEVEL2 → LEVEL3 .
• Radar videos do not become obscure because of the thinning of radar trails.
OFF : Disables the Trails Reduction function.
LEVEL1 : Enables the Trails Reduction function. (Effect: Low)
LEVEL2 : Enables the Trails Reduction function. (Effect: Modest)
LEVEL3 : Enables the Trails Reduction function. (Effect: High)
