8─33
Replacement of LCD Monitor
1 NWZ-164 (Display Unit: NCD-4340)
(1) Disconnect the cable from the connectors “VIDEO” on the rear of the processor and the power cable of
LCD monitor.
(2) Softly place the LCD monitor on a desk covered with a soft cloth.
(3) Attach a new LCD monitor in the reverse sequence as described above.
z When replacing the LCD monitor, which is easily
broken by a little impact, handle it carefully and do
not hit any article against it or put it on a hard article.
Attention
To Next Page
