JRC JMA-5206 User Manual

3─13
Display Color Setting
1. Day /Night
DAY1
2. Color Scheme
ORIGINAL
3. Outer PPI
GRAY
4. Inner PPI
BLACK
5. Character
WHITE
6. RADAR Echo
YELLOW
7. RADAR Trails ( Time )
CYAN
8. RADAR Trails ( Cont )
WHITE
9. HL/Vector/ATA/AIS
0. EXIT
1.
BLUE
2.
DARK BLUE
3.
BLACK
4.
GRAY
WHITE
Setting Colors of Items
Set the display color of each item.
Procedures 1 While the Display Color Setting Menu
is open, select the item number for
color setting, pressing the numeric
keys [3] to [8].
The color selection screen will appear.
3. Outer PPI: Adjusts the background color outside the
bearing scale.
4. Inner PPI: Adjusts the background color inside the
bearing scale.
5. Character: Adjusts the colors of characters and
bearing scales.
6. RADAR Echo: Adjusts the colors of radar echoes.
7. 8. RADAR Trails: Adjusts the colors of radar trails.
Time: Display interval time is selected.
Cont:
Continuous display
9. HL/Vector/ATA/AIS:
Adjusts the colors of HL, Vectors, ATA,
and AIS.
2 Select the color number to be set,
pressing the numeric key.
The selected color will be set.
To set more than one color, repeat steps 1
and 2.
Exit 1 Press [RADAR MENU] key.
The menu will be closed.
