3─112
3
3.10 APPLIED OPERATIONS
y
y y
JRC/ERC Setting
1. LAT/LON Line
LINE NUM
2. Color of L/L Line
BLUE
3. Bright of L/L Line
HIGH
4. ERC Display Request
ON
5. ERC Mark
SMALL
6. JRC Card Display Setting
7. Copy JRC Chart to CF
8. Fishing Area Display
OFF
0. EXIT
[4] Color of Sea
• Select the color of sea display.
• There are four selection items: GRAY , CYAN , BLUE , and GREEN .
Note: This function is available on the plotter mode only.
[5] Bright of Sea
• Select the brilliance of sea display.
• There are four selection items: OFF , LOW , MEDIUM , and HIGH .
Note: This function is available on the plotter mode only.
[6] Color of Name
• Select the color of a location name.
• There are eight selection items: BLACK , WHITE , CYAN , BLUE , GREEN ,
YELLOW , PINK , and RED .
[7] Bright of Name
• Select the brilliance of location name display.
• There are four selection items: OFF , LOW , MEDIUM , and HIGH .
[8] Bright of Track/Mark/Line
• Select the brilliance of track, mark and line..
• There are four selection items: LEVEL1 , LEVEL2 ,
LEVEL3 , and LEVEL4 .
[9] Next Page
• Moves to the next page.
• The next page of the JRC/ERC Setting Menu will appear.
[1] LAT/LON Line
• Select the mode to display latitude and longitude lines.
• There are two selection items:
LINE NUM : Displays both latitude/longitude lines
and values indicating the latitude and
longitude.
NUM : Displays only the values indicating the
latitude and longitude.
[2] Color of L/L Line
• Select the colors that are to represent latitude and longitude lines.
• There are eight selection items:
BLACK , WHITE , CYAN , BLUE , GREEN ,
To Next Page
