JRC JMA-5206 User Manual

- xix -
APPENDIX
FIGURE 1 JMA-5206/HS, JMA-5210-4/6, JMA-5220-7/9 BLOCK DIAGRAM
FIGURE 2 JMA-5206/HS INTERCONNECTION DIAGRAM
FIGURE 3 JMA-5210-4/6 INTERCONNECTION DIAGRAM
FIGURE 4 JMA-5220-7/9 INTERCONNECTION DIAGRAM
FIGURE 5 PRIMARY POWER SUPPLY DIAGRAM TYPE JMA5206/HS,
JMA-5210-46,JMA-5220-7/9
FIGURE 6 PROCESSOR UNIT NDC-1340 NTERCONNECTION DIAGRAM
FIGURE 7 KEY BOARD UNIT, NCE-7699 INTER CONNECTION DIAGRAM
FIGURE 8 JMA-5200 ON-SCREEN CONTROLS
ENVIRONMETAL PROTECTION
NAMES & CONTENT OF TOXIC AND HAZARDOUS SUBSTANCES OR
ELEMENTS

JRC JMA-5206 Specifications

General

Brand	JRC
Model	JMA-5206
Category	Marine Radar
Language	English
