8─98
8.6 Setting
yyyy
yyyy
8
Adjustment of Performance Monitor (NJU-64)
* Execution of this item needs a PM unit (option).
JMA-5206/HS has no PM option.
Procedures 1 Set the radar to Master Radar when the Interswitch is installed.
2 Press VRM1 key to display VRM1 and set the range of VRM1 to 10-18*
NM.
3 The Equipment Setup Menu will appear in accordance with the
instructions of section 8.5.
4 Press [4] key.
The TRX Setting Menu will appear.
5 Press [4] key.
The Code Input Menu will appear.
6 Enter a set value.
Adjust the PM pattern so that its outer edge is
within 10 to 18 NM. The multi-function control
is also available for the entry. After having
enter the value, press ENT.
7 Attach the INFORMATION LABEL
provided with the performance monitor
to an appropriate position on the
display unit.
RX Setting
1. Anntena Height
5-10m
2.
une Peak Adjust
0
0
8.Antenna Location
0. EXIT
3.
une Indicator Adjust
0
4. PM Adjustment
5.Manual Tune Adjustment
2048
7. Output Pulse
0m0m
To Next Page
