3─7
Menu Operation with the Trackball
The menu items are software buttons that can be operated with the trackball.
An item can be selected by pointing the trackball cursor to the item and pressing [ENT] key, instead
of using the numeric key.
Example of menu display
Process Setting
1. Video Latitude
NORMAL
2. VD Noise Rejection
LOW
3. Auto DR Control
ON
4. Process Switch
OFF
5. 2nd Process Mode
REMAIN
6.Process Switch Range
6.2nm
7. Fast Target Detection
OFF
8. User Function Setting >
0. EXIT
NORMAL
1.
WIDE
2.
NARROW
3.
Item number
Software button
The selected item is
displayed by pressing the
corresponding numeric
key.
An item can be selected by
pressing the corresponding
numeric key.
An item can also be
selected by the trackball
and by pressing [ENT]
ke
y
.
An item can also be
selected by pointing the
trackball cursor to the item
and pressing [ENT] key.
Press [8] key to move to
the lower level.
Movement to the lower
level can also be done by
pointing the trackball
cursor to the item and
p
ressin
g
[ENT] ke
y
.
Press [0] key move to the
higher level. Movement
to the higher level can also
be done by pointing the
trackball cursor to 0.EXIT
and pressing [ENT] key.
Super Wide
4.
