3─25
EBL Bearing Display
The bearing values of EBL1 and EBL2 currently displayed on the PPI are indicated at the lower right of
the radar display.
The currently operable EBL1 or EBL2 is shown in reverse video beside the bearing value.
Starting Point of EBL
The starting point of the currently operating EBL can be switched from the center of the radar display
(CENTER) to any offset position (OFFSET).
Note: The offset position of the EBL’s starting point can be fixed on the radar display or at specific
latitude and longitude. (For details, refer to page 3-28.)
[I] Offsetting the starting point of EBL1 while EBL1 is operating:
Procedures 1 Press the [EBL] control.
The indication C to the right of the EBL value at the lower right of the radar display
will change to O , and “OFFSET” will be set.
* Button
35
on the radar display on page 2-7 is also available to switch the offset of EBL1.
* Button
36
on the radar display on page 2-7 is also available to switch the offset of EBL2.
2 Move the starting point of EBL1 with the trackball.
3 Press [ENT] key at the starting point of EBL1 you want to move.
The starting point of EBL1 will be determined.
If EBL2 is operating, the starting point of EBL2 is offset.
[II] Moving the starting point of EBL1 to the own ship’s position while EBL1 is
operating:
Procedures 1 Press the [EBL] control twice.
The indication O to the right of the EBL value at the lower right of the radar display
will change to C , and “CENTER” will be set.
* Button
35
on the radar display on page 2-7 is also available to switch EBL1 CENTER.
* Button
36
on the radar display on page 2-7 is also available to switch EBL2 CENTER.
If EBL2 is operating, the starting point of EBL2 moves to the own ship’s position.
To Next Page
