22. COMMUNICATION SCREEN OF MAINTENANCE
PERSONNEL LEVEL
For the communication screen, the level which is normally used and the one which is used by the
maintenance personnel are different in the kinds of data to be handled.
22-1 Data which are possible to be handledIn case of the maintenance
personnel level, it is possible to use 5 different kinds of data in addition to the normal two kinds.The
respective data formats are as below.
Data name Pictograph Extension Description of data
Adjustment data
Model name+00
.msw
Example) DP00001.msw
Data of memory switches 1 and
2
All sewing machine data
Model name+00
.msp
Example) DP00001.msp
Al l d ata which a re h el d by
sewing machine
Panel program data
AP+RVL(6 digits).hed
AP+RVL(6 digits).p(2 digits)
AM+RVL(6 digits).i(2 digits)
Program data and display data
of panel
Main program data
MA+RVL(6 digits).prg
Program data of main
Servo program data
MT+RVL(6 digits).prg Program data of servo
