15
–
5.
OPERATION OF THE SEWING MACHINE (SEMI-AUTOMATIC BASIC VOLUME)
5-1 Data input screen
8 9
1
2
A
B
C
3
4
5
6
!5
!2
!3
F
D
E
7
!0
!1
!6
!4
!7
G
No. Button Name of button Description
1
PATTERN SELECTION button Pattern No. being selected at present is displayed on the
button and when the button is pressed, PATTERN No.
CHANGE screen is displayed.
2
DIRECT SELECTION button When the button is pressed, the list screen of pattern
Nos. which are registered in DIRECT SELECTION button
is displayed.
3
LEFT/RIGHT/ALTERNATE
SEWING SELECTION button
Changeover method of program (for right sleeve and left
sleeve) during sewing is selected.
4
STEP SELECTION button When the button is pressed, the step becomes in the
state of selection.
5
SHIRRING AMOUNT FOR
AUXILIARY FEED button
When the button is pressed, shirring amount for auxiliary
feed change screen is displayed.
6
SHIRRING AMOUNT button When the button is pressed, shirring amount of the step
being selected is changed.
To Next Page
