Juniper MX10016 Hardware Guide

Figure 2 on page 24 illustrates the components that are visible from the rear of the chassis.
Figure 2: MX10016 Chassis Rear
3—1— ESD pointAC or DC power supplies
4—2— Protective earthing terminalFan trays with redundant fans
Figure 3 on page 25 illustrates the components that are internal to the chassis.
