Juniper MX10016 Hardware Guide

Table 6: MX10016 Chassis Physical Specifications
DepthWidthHeightWeightDescription
35 in.
(88.9 cm)
17.4 in. (44.2 cm)
NOTE: The outer edges of the
mounting-bracket flange extend
the width to 19 in. (48.3 cm).
36.6 in.
(92.96 cm)
220 lb
(99.79 kg)
Chassis, spare
35 in.
(88.9 cm)
17.4 in. (44.2 cm)
NOTE: The outer edges of the
mounting-bracket flange extend
the width to 19 in. (48.3 cm).
36.6 in.
(92.96 cm)
522 lb
(236.78 kg)
Chassis base AC configuration
Includes 1 Control Board, 5 AC
power supplies, 2 fan trays, 2 fan
tray controllers, and 5 Switch
Ffabric Boards (SFBs)
35 in.
(88.9 cm)
17.4 in. (44.2 cm)
NOTE: The outer edges of the
mounting-bracket flange extend
the width to 19 in. (48.3 cm).
36.6 in.
(92.96 cm)
596 lb
(270.34 kg)
Chassis redundant AC
configuration
Includes 2 Control Boards, 10 AC
power supplies, 2 fan trays, 2 fan
tray controllers, and 6 SIBs
35 in.
(88.9 cm)
17.4 in. (44.2 cm)
NOTE: The outer edges of the
mounting-bracket flange extend
the width to 19 in. (48.3 cm).
36.6 in.
(92.96 cm)
519.5 lb
(235.65 kg)
Chassis base DC configuration
Includes 1 Control Board, 5 DC
power supplies, 2 fan trays, 2 fan
tray controllers, and 5 SIBs
35 in.
(88.9 cm)
17.4 in. (44.2 cm)
NOTE: The outer edges of the
mounting-bracket flange extend
the width to 19 in. (48.3 cm).
36.6 in.
(92.96 cm)
591 lb
(268.07 kg)
Chassis redundant DC
configuration
Includes 2 Control Boards, 10 DC
power supplies, 2 fan trays, 2 fan
tray controllers, and 6 SIBs
