Table 8: Status Panel LEDs in an MX10016 Router (continued)
DescriptionStateColorName
The fans and the fan tray controllers are
online and operating normally.
On steadilyGreenFans
There is an error in a fan or in one of the
fan tray controllers.
On steadilyYellow
The fan tray controllers and fan trays are
not receiving power.
OffNone
All installed Switch Fabric Boards (SFBs)
are online.
On steadilyGreenSFBs
There is a hardware error in one or more
SFBs.
BlinkingYellow
All the SFBs are offline.OffNone
All the line cards are online.On steadilyGreenLine cards
There is a hardware error in one or more
line cards.
BlinkingYellow
All the line cards are offline.OffNone
All the RCBs are online.On steadilyGreenRouting and Control Boards
One or more Routing and Control Boards
have an error condition.
BlinkingYellow
All the installed Routing and Control
Boards are offline.
OffNone
