CAUTION: Before you install the router, ensure that a licensed electrician has attached
an appropriate grounding lug to the grounding cable that you supply. Using a grounding
cable with an incorrectly attached lug can damage the router.
NOTE: The base configuration of MX10016 routers are shipped with five power supplies. Cover
are installed over the remaining power supply slots. You can add additional power supplies to base
configuration routers as necessary. For details about different router configurations, see “MX10016
Components and Configurations” on page 31.
Each JNP10K-PWR-AC power supply weighs approximately 6.8 lb (3.08 kg) and has two independent
16-A rated AC inlets on the faceplate. Although each inlet provides sufficient input power to provide full
output, always connect to a dedicated AC power feed to provide redundancy. Only one power feed is
operational at a time.
The MX10016 routers employ automatic transfer switch (ATS) technology. The MX10016 power system
provides 2nsource redundancy. If one power source fails, ATS routes the power supply to the alternate
source.
NOTE: For redundancy, always plug the two power cords from each power supply:
•
INP1 into an uninterruptible power supply (UPS)
•
INP2 into the public electricity supply
Each JNP10K-PWR-AC power supply has a power switch with international markings for on (|) and off
(O), a fan, and four LEDs on the faceplate that indicate the status of the power supply. See
Figure 23 on page 60.
