MULTICAL®603
KamstrupA/S∙Technicaldescription∙55122029
_
A1_GB
_
06.2017
121
Thelimitationsconnectedtotheuseof2wiresensorpairsaccordingtoEN14342:2015appearfromthetablebelow.
Cablecross
sectionmm
2
Pt100sensors Pt500sensors
Maxcablelength
m
Subjectto
EN14342:2015
Temperatureincrease
K/m
Copper@20C
Maxcablelength
m
Subjectto
EN14342:2015
Temperatureincrease
K/m
Copper@20C
0.25 2.5 0.450 12.5 0.090
0.50 5.0 0.200 25.0 0.040
0.75 7.5 0.133 37.5 0.027
1.50 15.0 0.067 75.0 0.013
Table6
4wiresensorset
Forinstallationsrequiringlongercablelengthsthanstatedinthetableabove,itisrecommendedtouse4wire
sensorsetsaswellasMULTICAL
603type603B/D/Gwith4wireconnection.
The4wireconstructionusestwoconductorsforthemeasuringcurrentandtwootherconductorsforthemeasuring
signal,whichmeansthattheconstructionintheoryisuninfluencedbylongsensorcables.Inpractice,cablesought
nottobelongerthan100
m,anditisrecommendedtouse4x0.25mm
2
.
Theconnectioncableoughttohaveanouterdiameterof56mminordertoobtainoptimumtightnessofboth
MULTICAL
603andthescrewjointforthe4wiresensor.Theisolationmaterial/coverofthecableoughttobe
selectedonthebasisofthemaximumtemperatureintheinstallation.PVCcablesarenormallyusedupto80C,and
forhighertemperaturessiliconecablesareoftenused.
