EE=14Inlettem peraturetariff
Ifthecurrentinlettemperature(t1)exceedsTL2butislowerthanorequaltoTL3,energyiscountedinTA2parallelto
themainregister.IfthecurrentinlettemperatureexceedsTL3butislowerthanorequaltoTL4,energyiscountedin
TA3parallel
tothemainregister.IfthecurrentinlettemperatureexceedsTL4,energyiscountedinTA4paralleltothe
mainregister.

t1TL2
Accumulationinmainregisteronly
TL4TL3TL2
TL3t1TL2
AccumulationinTA2andmainregister
TL4t1TL3
AccumulationinTA3andmainregister
t1TL4
AccumulationinTA4andmainregister

Settingupdata,TL3mustbehigherthanTL2andTL4mustbehigherthanTL3.
The inlet temperature tariff can  be used as a basis for billing consumers who are guaranteed a certain inlet
temperature.Ifthe“gua ranteed”minimumtemperatureisenteredinTL4,thepayableconsumptionisaccumulat ed
inTA4.

EE=15Outlettemperature tariff
Ifthecurrentoutlettemperature(t2)exceedsTL2,butislowerthanorequaltoTL3,energyiscountedinTA2parallel
tothemainregister.IfthecurrentoutlettemperatureexceedsTL3,butislowerthanorequaltoTL4,energyiscounted
inTA3paralleltothemainregister.IfthecurrentoutlettemperatureexceedsTL4,energyiscountedinTA4parallelto
themainregister.

t2TL2
Accumulationinmainregisteronly
TL4TL3TL2
TL3t2TL2
AccumulationinTA2andmainregister
TL4t2TL3
AccumulationinTA3andmainregister
t2TL4
AccumulationinTA4andmainregister

Settingupdata,TL3mustbehigherthanTL2andTL4mustbehigherthanTL3.
Theoutlettemperaturetariffcanbeusedasabasisofweightedusercharge.Ahighoutlettemperatureindicates
insufficientheatutilizationwhichisuneconomicalfortheheatsupplier.
 
