MULTICAL®603
KamstrupA/S∙Technicaldescription∙55122029_A1_GB_06.2017
39
Thetablebelowisapartofthetypenumberoverview,whichshowsthemoduletypenumbers.Thetable
distinguishesbetweenmoduleswithpulseinputs(InA,InB)andmoduleswithpulseoutputs(OutC,OutD).
Modules
Data+2pulseinputs(InA,InB) 10
Data+2pulseoutputs(OutC,OutD) 11
MBus,configurable+2pulseinputs(InA,InB) 20
MBus,configurable+2pulseoutputs(OutC,OutD) 21
MBus,configurable+ThermalDisconnect 22
WirelessMBus,configurable,868MHz+2pulseinputs(InA,InB)
1
30
WirelessMBus,configurable,868MHz+2pulseoutputs(OutC,OutD)
1
31
Analogoutputmodule2x0/4…20mA 40
Analoginputmodule2x0/4…20mA 41
KamstrupRadio+2pulseinputs(InA,InB) 50
LONFTX3+2pulseinputs(InA,InB) 60
BACnetMS/TP+2pulseinputs(InA,InB) 66
ModbusRTU+2pulseinputs(InA,InB) 67
HighPowerRadioRouter+2pulseinputs(InA,InB) 84
1
Internalorexternalantenna
MULTICAL
603registerstheaccumulatedconsumptionofthemetersconnectedtotheinputsandsavesthecounter
valueseverymonthandeveryyearontargetdate.Thenumberoftheseyearlyandmonthlyloggingsdependsonthe
selectedloggerprofile(RRcode).Readmoreaboutdataloggerprofilesinparagraph3.2.11.
Inordertofacilitatethe
identificationduringdatareading,itisalsopossibletosavethemeternumbersofthefourmetersconnectedtothe
inputs. The meter numbers can either be programmed in the meter via the SETUP loop (for A1 and B1) or via
METERTOOLHCW(forA1,B1,
A2andB2).
Two alarm types are connected to the pulseinputs, cold waterleakage and external alarm, respectively. Unless
otherwiseinformedbythecustomer,themeterisbydefaultpreparedforexternalalarmonallfourinputsfromthe
factory,butonlywithactiveleakagealarmoninput
A1andA2(likeinMC602).PleasecontactKamstrupA/Sifyou
needleakagealarmpossibilityoninputB1andB2.Readmoreaboutcoldwaterleakageinparagraph3.2.9andmore
aboutinfocodesinparagraph7.7.

Note:
Theselecteddatagramprofileofthemodule,configuredthroughthemodule’sZZZcode,controls
whichpulseinputregistersarecollectedthroughthemodule.Bydefault,InA1andInB1arecollected.
