Adaptivemode(2‐64s)
Adaptivemodeisthemeter’sintelligentintegrationmode,inwhichthetimeintervaliscurrentlyadjusted.Thismode
combinesthelong batterylifetime obtainedin Normalmodewiththe highmeasuringand calculationresolution
obtainedinFastmode.
Whenthethermalsystemisstable,i.e.runs
atstableflowandpower,themeterwilluseatimeintervalof64s.
MULTICAL®603continuouslymeasuresifflowandpowerhavechanged,andifthisisthecase,reducestheinterval.
Dependingonthechange,themetercanreducetheintegrationintervalto2seconds,whichmeans
thatthemeter
calculates accumulatedvolumeand energyevery 2seconds.Thereby,higherresolution and higherprecision are
obtainedduringperiodswithchangesinthesystem.MULTICAL®603’sadaptivealgorithmreactstoflowchangesdown
to1%.
Forapplicationswithtwoflowsensors,itisworthnotingthatMULTICAL®603
onlymeasureschangesinflowand
powerofV1andnotofbothV1andV2.ThismeansthattheintegrationofregistersrelatedtoV1andV2,
respectivelytakesplaceatthesametimeandistime‐based.Inadaptivemode,theintegrationintervalisonly
adjustedaccordingtothechangesofV1.
Whenthesystemisstable,themetergraduallyreturnstothe64s.interval.MULTICAL®603reactsquicklytochanges
inthesystembylowering
thetimeinterval;however,itgraduallyreturnstothetimeintervalof64s.asthesystem
becomesstable.Thisisillustratedinthefigurebelow.

Thus, in adaptivemode MULTICAL® 603 measures athigh resolution during periods with changes inthe system
requiringaccuratemeasurementsandsavesbatterypower
duringperiodswithnochangesinthethermalsystem.
Adaptivemodeisrecommendedforallsystemsincludingthosewithtapwaterexchanger.
Normalmode(32s) 
Innormalmodetheintegrationintervalissetat32seconds,whichmeansthatthemetercalculatesaccumulated
volumeandenergyevery32seconds.
Normalmodeisrecommendedforsystemswithhotwatertankandsimilarsystemsinwhichchangesarenottaking
placetooquickly.
 
Integration time

Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
