Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

64
KamstrupA/S∙Technicaldescription∙5512‐2029
_
A1_GB
_
06.2017

Bymeansofthemeter’sfrontkeys,youcanchoosefromandswitchbetweenthefourdisplayloops.Whendelivered,
themeterisintransportstate,whichmeansthattheUSER,TECHandSETUPloopsareavailable.Dependingonthe
countrycode,theaccesstotheSETUPloopmaybeblocked
intransportstate,andtheSETUPloopisthusnotavailable
ondelivery.TheTESTloopcanonlybeaccessedifthetestseal(verificationseal)isbroken.
Bykeepingtheprimarykeyactivatedfor5seconds,younavigatetoLOOPselect.Here,youcanusethearrowkeysto
switchbetweenthemeter’sdisplayloops.IntheTECH,SETUPandTESTloops,indexnumbersareusedasthereadings
inthesedisplayloopsareallocatedtoaspecificindexnumber.Theindexnumbersfacilitatenavigationtotherequired
reading.IndexnumbersarenotusedintheconfigurableUSERloop.The
belowfigureillustrateshowitispossibleto
navigateinthemeter’sdisplaybymeansofthefrontkeys.


Readingsincaseoferror
Inordertofacilitatethediagnosticswork,linesareshowninthedisplayreadings(currentvalues)whichareinfluenced
bytheerror,andatthesametime,countingstopsintheregisters,whicharedependingonthegivenparameterand
thusinfluencedbyth eerror.
Incaseofinterruptedorshort‐circuitedtemperaturesensorthecorrespondingdisplay
readingwillincludelines.MULTICAL®603reg isterstheseerrorsandsetsaninfocode,whichcaneasilybereadfrom
thedisplay.Readmoreaboutinfocodesinparagraph7.7.

Readingoft2incaseoftemperature
sensorerror

Reading of temperature difference
t1‐t2attemperaturesensorerror

Errorinpowerreadingasaresultof
temperaturesensorerror



Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
