MULTICAL®603

86
KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017

EnergytypesE1…E7aredescribedbyapplicationexamplesbelow.



603‐A/B/C/D/E/F/G
Applicationno.1

Closedthermalsystemwith1flowsensor

Heatenergy:E1=V1(t1‐t2)k
t1:inletort2:outlet


Coolingenergy:E3=V1(t2‐t1)k
t2:inletort1:outlet


FlowsensorV1ismountedininletoroutletas
selectedduringconfiguration.

Mass:M1=V1(Kmasst1)or
Mass:M1=V1(Kmasst2)dependingoninlet/outlet
programming.

ConfigA=3(inlet)or4(outlet)


603‐E/F
Applicationno.2

Closedthermalsystemwith2identicalflowsensor s 
Leakagemonitoring
Permanentoperationalmonitoring

Billingenergy:E1=V1(t1‐t2)k
t1:Inlet


Controlenergy:E2=V2(t1‐t2)k
t2:Outlet


t3canbeusedforcheckmeasurementofeitherthe
inletoroutlettemperature,butt3isnotusedfor
theenergycalcula tion.

Mass:M1=V1(Kmasst1)
Mass:M2=V2(Kmasst2)

Config.A=3(Inlet)
 

Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
