Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017
87



603‐E/F
Applicationno.3

2stringsyste mwith2flow sensors

Heatenergy:E1=V1(t1‐t2)k
t1:inletort2:outlet


Tapwaterenergy:E6=V2(t3‐t4)k
t3:Inlet


t3ismeasuredorprogrammed
t4isprogrammed.

FlowsensorV1ismountedininletoroutletas
selectedduringconfiguration.

Mass:M1=V1(Kmasst1)or
Mass:M1=V1(Kmasst2)dependingoninlet/outlet
programming.
Mass:M2=V2(Kmasst3)*

ConfigA=3(inlet)or
4(outlet)


603‐E/F
Applicationno.4

2heatingcircuitswithjointforwar dpipe

Heatenergy#1:E1=V1(t1‐t2)k
t2:Outlet


Heatenergy#2:E7=V2(t1‐t3)k
t3:Outlet


t3ismeasuredorprogrammed
Mass:M1=V1(Kmasst1)
Mass:M2=V2(Kmasst3)*





Config.A=4(outlet)

*M2=V2(Kmasst3).V2ismass‐adjustedwitht3whenselectingspecialDDD‐code.

